Constant Moment Beam Load Cell With 4-Direction Overload Stops

Original price was: $357.00.Current price is: $96.99.

5-Point NIST Traceable Calibration with
59 kOhm Shunt Cal Data
4-Direction Overload Stops
0.25% Interchangeability for Scale Applications

Weight Capacity

Measurement Units

Force direction

Clear

SKU: LC601-25 Categories: Force & Strain Measurement, Load Cells Tag: Omega Engineering

Hassle-Free Payments
Online assistance, always at your service.
Your needs, our top priority.
Safe Payments, Happy Customers

OMEGA’s Model LC601 is an extremely low capacity industrial load cell with built-in overload stops in all four directions for added durability . The LC601 offers high accuracy and a rugged design in a small package. It is ideal for small scales and industrial weighing applications.

The LC601 is also available in metric configurations, with 0-1 to 0-10 kgf ranges and metric threads. Please see the LCM601 for complete details, or contact our Pressure department for more information.

SPECIFICATIONS
Excitation: 10 Vdc, 15V max
Output: 2 mV/V ±0.25%
5-Point Calibration (in Compression): 0%, 50%, 100%, 50%, 0%
Linearity: ±0.03% FSO
Hysteresis: ±0.03% FSO
Repeatability: ±0.02% FSO
Zero Balance: ±1% FSO
Operating Temperature Range: -34 to 82°C (-30 to 180°F)
Compensated Temperature Range: 16 to 71°C (60 to 160°F)
Thermal Effects:
Zero: ±0.0025% FSO/°F
Span: ±0.0010% FSO/°F
Safe Overload: 150% of rated capacity
Ultimate Overload: 300% of capacity
Input Resistance: 360 ? minimum
Output Resistance: 350 ±10 ?
Full Scale Deflection: 0.005 to 0.015″ typ
Construction: Stainless steel
Electrical Connections: 1.5 m (5′) 4-conductor shielded color-coded cable

Weight Capacity	25 lbf, 2 kgf
Measurement Units	lbf, kgf
Force direction	Tension/Compression, Compression
Linearity	±0.03%
Electrical Output (nominal)	2 mV/V
OD	1"
Length	4.5"
Connection Type	Cable
Cable Length	5 ft
