Metric, Lightweight, Aluminum S-Beam Load Cells

Original price was: $310.00.Current price is: $95.99.

5-Point NIST Traceable Calibration with
59 kOhm Shunt Cal Data
High Accuracy
Aluminum for Light Weight and Durability
Calibrated in Tension

SKU: LCM105-500 Categories: Force & Strain Measurement, Load Cells Tag: Omega Engineering

Hassle-Free Payments
Online assistance, always at your service.
Your needs, our top priority.
Safe Payments, Happy Customers

The LCM105 & LCM115 are also available in standard configurations, with 0-25 to 0-1000 lb ranges and standard threads. Please see the LC105 for complete details, or contact our Pressure department for more information.

SPECIFICATIONS
Excitation: 10 Vdc, 15 Vdc max
Output: 3 mV/V ±.0075 mV/V
Linearity: ±0.03% FSO
Hysteresis: ±0.05% FSO
                   ±0.02% FSO
Repeatability: ±0.01% FSO
Zero Balance: ±1% FSO
Operating Temp Range: -40 to 93°C (-40 to 200°F)
Compensated Temp Range: 17 to 71°C (60 to 160°F)
Thermal Effects:
   Zero: 0.002% FSO/°C
   Span: 0.002% rdg/°C
Safe Overload: 150% of Capacity
Ultimate Overload: 300% of Capacity
Bridge Resistance: 350 ± 5 Ohms
Full Scale Deflection: 0.25 to 0.50 mm (0.010 to 0.020″)
Construction: Aluminum
Electrical (4-conductor shielded cable:)
   <250 kg: 9 m (30 ft) 24 AWG
   >100 kg: 9 m (30 ft) 20 AWG
LC115/LCM115 Mating Connector: PT06F10-6S, sold separately

Weight Capacity	500 kgf
Measurement Units	kgf
Force direction	Tension/Compression
Linearity	±0.03%
Electrical Output (nominal)	3 mV/V
OD	N/A
Height	3"
Width	1"
Length	2"
Connection Type	Cable
Cable Length	2.5 ft
