SPAN RESISTORSTemperature Compensation For Strain Gage Bridges

Original price was: $27.99.Current price is: $19.59.

FAST IMMEDIATE DELIVERY ON LARGE ORDERS!
Stock to 1-Week!
Conveniently Priced per Pack of 5

Grid length

Grid Width

Resistance

Features

Clear

SKU: SGN-2/20-E Categories: Force & Strain Measurement, Strain Gauge Accessories, Strain Gauges Tag: Omega Engineering

Hassle-Free Payments
Online assistance, always at your service.
Your needs, our top priority.
Safe Payments, Happy Customers

Use these high stability resistors to do span and temperature compensation on your strain bridge circuits.
SPECIFICATIONS
Foil Measuring Grid:Nickel foil 5 microns thick
Carrier: Polyimide
Substrate Thickness: 20 microns
Cover Thickness: 25 microns
Tolerance in Ω: ±1 Ω
Temp Coefficient of Resistance:0.6%/°C (0.34%/°F)
Temperature Range: 0 to 100°C (32 to 212°F)

Grid length	2 mm, 3 mm, 4 mm
Grid Width	3 mm, 3.2 mm
Resistance	20 Ω, 25 Ω, 30 Ω, 10 Ω, 12 Ω, 34 Ω, 36 Ω, 14 Ω, 16 Ω, 24 Ω, 28 Ω, 32 Ω, 48 Ω, 60 Ω
Features	Encapsulated Temperature Compensation Resistors, Open Face Temperature Compensation Resistors
Grid Style	Span Resistors
